| Item | 24 LEDs | 36 LEDs |
|---|---|---|
| LED’s | 24 | 36 |
| Current | 300 – 1050 mA | |
| Power | 15.8 W – 54.8 W | 34 W – 100 W |
| PF | > 0.95 | |
| V / Hz | 90 – 305 V / 50 – 60 Hz | |
| Driver | INVINTRONICS / PHILIPS / OSRAM | |
| Control Option | DALI / 0–10 V / Astro DIM / Step DIM / Smart Control Ready | |
| Item | 24 LEDs | 36 LEDs |
|---|---|---|
| Efficacy | 160 lm/W | |
| Luminous Flux | 2,528 lm – 8,768 lm | 5,440 lm – 16,000 lm |
| CRI | > 70 Ra | |
| CCT | > 4000 K | |
| Beam Angle | TYPE II K13 | |
| LED Module | Seoul 5050 | |
| Board Type | SMD | |
| Lens | Polycarbonate | |
| Optical Cover | Tempered Glass | |
| Dimensions | 539 × 248 × 132 mm |
|---|---|
| Mounting | Side fitting / Top fitting |
| Installation Pipe | Ø48 mm / Ø60 mm / Ø76 mm |
| Pole Height | 10 m – 12 m |
|---|---|
| Max Wind Load Area | 0.15 m² |
| Weight | 5 kg |
| Container | Size (mm) | Per Carton (pcs) | Per Container (pcs) | Net Weight (kg) per 1 / per container | Gross Weight (kg) per 1 / per container |
|---|---|---|---|---|---|
| 20FT (5.85×3.23×2.15) | 660×280×175 | 1 | 1400 | 5 / 7000 | 5.9 / 8260 |
| 40GP (11.8×2.13×2.18) | 660×280×175 | 1 | 2600 | 5 / 13000 | 5.9 / 15340 |
| 40HQ (11.8×2.13×2.72) | 660×280×175 | 1 | 3250 | 5 / 16250 | 5.9 / 19175 |
